Did the Huygenses “buy” Spinoza’s lens polishing technique?

The Meteoric Rise of Huygens’s Microscope

The following is an exercise in historical imagination, only meant to elicit what is possible from what we know. Perhaps a fiction bent towards fact.

Wim Klever has brought to my attention a detail which sheds some light upon the possible lens polishing techniques Spinoza employed. Admittedly the connective tissue for a conclusion is not there, but the inference remains.

Professor Klever tells me that in his “Insignis opticus: Spinoza in de geschiedenis van de optica” he cites Freundenthal’s publication of the advertisement of the auction of the Spinoza’s estate in the Haarlemse Courant. The advertisement was printed on November 2nd, and occurred on November 4th (almost 9 months after Spinoza’s death). It seems likely that Constantijn Huygens jr., and/or his brother the famed scientist Christiaan,  bid at and purchased what remained of Spinoza’s estate. This is how Wim Klever roughly translates some of the items:

books, manuscripts, telescopes (‘verrekyckers, mind the plural!), microscopes (‘vergrootglazen’, also plural), glasses so grinded (‘glazen soo geslepen’), and various instruments for grinding (‘en verscheidene slypgereedschap’) like mills (‘molens’, also plural!) and great and small metal dishes serving for them (‘groote en kleine metale schotels daartoe dienende’) and so on” (en so voort).

It is the number of devices and equipment that is Klever’spoint. Spinoza is not a dabbler in optics. He does not grind a few spectacle glasses for the near-sighted, but rather is interested in full-blown optical instrument production. There are multiple telescopes and microscopes to be had, as well as perhaps something more important, his grinding dishes, and at least two lathes or mills not to mention other small details of his process. Certainly the bill of sale attests to a rather thorough industrial investment on Spinoza’s part, making of his optical enterprises something quite substantial, but what I am most interested in here is the timing of this auction, in the view of the events that immediately are set to follow, events which may give clue to the nature of just what it is that Constantijn Huygens purchased for his brother.

Spinoza’s death, and auction occurs right at the doorstep of a very important moment in history: the official discovery of protozoa, bacteria, and then spermatozoa by Van Leeuwenhoek in nearby Delft. And it is this discovery which will eventually catapult the single lens simple microscope into European renown. But there is, I suggest, a good chance that Spinoza had been making, using, giving to others and possibly selling this kind of microscope for a very long while (Klever translates “vergrootglazen” as “microscope” as one should, but there is another word for microscope, and this word means “glass that magnifies” perhaps more suitable for a single lens microscope.)



First, I should point out that Christiaan Huygens had been a neighbor to Spinoza since 1663 when Spinoza moved to Voorburg, a sleepy village just outside ofThe Hague. He is a profound experimenter and scientist, having, among other remarkably brilliant things, invented the pendulum clock and discovered the rings of Saturn in the very same year of 1656. Spinoza had, most agree, become a conversational friendinthe summer of 1665, when the two of them discussed optical theory it seems with some regularity and detail. The Huygenses lived about a 5 minutes walk from Spinoza’s room at the house of master painter Daniel Tydeman, just down the road. Christiaan moved to Paris in 1666 to take the prestigious position of founding Secretary to Académie Royale des Sciences established by the Sun King Louis XIV to rival the Royal Society of London. There was no doubt extreme pressure to counter and surpass the great flow of knowledge that was collecting at the Royal Society under the supervision of Oldenburg.

During the intervening years, as Huygens attempted to bolster his Academy, in letters written to his brother back in Voorburg he expressed interest in Spinoza’s lens polishing technique. As early as 1667, he writes Constantijn “the [lenses] that the Jew of Voorburg has in his microscopes [I don’t have the original word here] have an admirable polish” and a month later again, “the Jew of Voorburg finishes his little lenses by means of the instrument and this renders them very excellent”. Here we have an attestation to both the mystery of the quality of Spinoza’s polish, (it was a technique which Spinoza apparently kept to himself); and also there is the hint that the instrument used was meant for very fine work, on the smaller of lenses. (In general, the difficulty in acquiring a fine polish on lenses was a significant aspect of lens-crafting technique, as polishing away the pitting of the glass brought in the grinding often would change the spherical shape of the lens.) In 1668 Christiaan then writes to his brother a concession over a debate that he must have been having with Spinoza, that Spinoza is right that the smallest objective lenses make the very best microscopes.

These references by Christiaan establish that the Huygens brothers’ had interest in techniques which Spinoza was not free with, and that Spinoza was on the side of the debate that theoretically would favor the use of single lens microscopes; this, at the very least, confirms their acquisition of his equipment and lenses to be something of a notable event. If there was anything to Spinoza’s technical capabilities which resided in the equipment he used (small grinding dishes, the nature of his lathe, an abrasive recipe, a polishing material), this fact might be evidenced by a sudden change in the capacities of either brother in making microscope lenses.

And remarkably, such a change was to come.

Now the issue of timing. Here is a timetable of events that led up to Christiaan Huygens presenting a “new microscope” to the Académie Royale des Sciences, one that perhaps reflects something of Spinoza’s technique in crafting lenses.

9 Oct. 1676  Van Leeuwenhoek sends his letter regarding the discovery of protozoa and bacteria.

21 Feb. 1677  Spinoza dies at the The Hague.

22 Feb. 1677  Van Leeuwenhoek’s letter 18 to the Royal Society is read aloud, the “first ever written account of bacteria” (Dobell).

August 1677 Van Leeuwenhoek discovers the animalcules in semen, spermatozoa

4 Nov. 1677 Spinoza’s auction, the Huygenses seem to have acquired some of Spinoza’s equipment.
@ 4 Nov. 1677 Van Leewenhoek writes to the president of the Royal Society, William Brouncker, about his observation of the spermatozoa in semen. This sample was brought to him by Leiden medical student Johan Ham (who also might have had a single lens microscope).
Late 1677 Christiaan expresses interest in the Van Leeuwenhoek/Ham discovery (OCCH 8:77; and 62-3, 65).

March 1678  Hartsoeker explains to Christiaan how he makes lenses from beads of glass.

16 July 1678  Christiaan presents to the Académie Royale des Sciences the “new microscope” that differs from others in Holland and England only in the very small size of the lens.

Aug. 1678  Christiaan writes “my microscopes” have made a “great noise” in Paris.

One must know that single lens microscopes had already been in use in the Netherlands for some time before these dates. It had been used, but its capacity for magnification had not been regularly harnessed to make scientific discovery. Part of this was due to a difficulty in using it, for it must be pressed very closely to the eye, requiring great patience, and lighting techiques for the specimen in contrast had to be developed. And part of this dearth of scientific discovery was due to simply the lack of a conceptual framework for the microscopic world. This was a new world. Few as yet would even know where and why to point such a small and powerful viewing glass. Be that as it may, the microscope technique of forming tiny bead lenses from threads of melted glass was certainly known and talked about in a close scientific circle of experimenting savants (a short history of the spherical glass here). Among those notables were Spinoza’s correspondent Johannes Hudde who made them at least since 1663 when he showed his design to the French diplomat Monconys, and possibly used it as early as 1659 when he youthfully writes in a letter how he will uncover the secrets of generation through its powers. The scholar Vossius has one in 1663 which he also shows to Monconys, and in 1666 publishes the claim that the smaller the lens the stronger the magnification. And then to greatest attention Hooke describes his own bead microscope in the Micrographia in 1665 (some comments here), complaining though that it is too difficult to regularly use, fearing the loss of his eyesight.



Hooke's Fly's Eye, from the Micrographia

And of course, it is the king of all microscopists, Van Leeuwenhoek, who exclusively employed this kind of microscope, making over 500 of them almost all for his personal use (some comments here). When he began using them is of much debate. He makes a claim late in life that had had made bead microscopes as early as 1659 (so simple are they to make!), yet some scholars find him to have been directly informed by the description left by Hooke in the Micrographia. We do not hear of his use until 1774, and the nature of his microscope he keeps secret for sometime. It is Van Leeuwenhoek’s microscope – upon the reading of his 18thletterto the Royal Society, the day after Spinoza’s death – that will suddenly take center stage through its discoveries (although its nature at this time remains largely unknown). The single lens microscope is the strongest microscope in the world, but only now will Christiaan Huygens be coming to realize it.

For many years it seems Johannes Hudde had to defend his tiny spherical lenses against Huygens’ intution that larger, compound scopes would do a better job. It seems quite likely that Spinoza found himself mostly on the Hudde side of the argument, even I think it likely that it was Hudde himself, or one in his circle who disseminated the technique to him, either in Amsterdam or at Leiden. To this possibility, the famed Leiden anatomist Swammerdam attributes Van Leeuwenhoek’s technique to Hudde, as he does his own’ and Borch in his diary mentions the heavy influence of Hudde upon these Cartesians. Apart from this debate, Christiaan as a user of the compound scope as late as January 1675 to Oldenburg expresses an outright pessimism towards Van Leeuwenhoek discoveries already relayed to the Royal Society. These may be founded on his own frustrations when attempting to repeat the experiments, as he simply did not have enough magnification power, or they may even be a product of Van Leeuwenhoek’s low social standing as a mere draper in Delft (while Christiaan does not strictly know what kind of microscope Van Leeuwenhoek possesses, he may have guessed. There may be a class issue that folds into the conception of the microscope. Bead lenses are simply, too simple. They are not the shiny, gearing tubes of an upper machinery):

I should greatly like to know how much credice Mr. Leeuwenhoek’s observations obtain among you. He resolves everything into little globules; but for my own part, after vainly trying to see some of the things which he sees, I much misdoubt me whether they be not illusions of his sight…(Dobell 172)

Christiaan Huygens Makes His Turn

But back to the excitment. Something has turned Christiaan Huygens’ pessimism of the simple microscope into an enthusiasm. Most certainly some of this can be attributed to the sudden notability of Van Leeuwenhoek’s discovery of the protozoa and bacteria in marshy and boggy water. In November he will have discovered what male semen looks like under high magnification. At stake were arguments over just how Life itself was generated. (Did it arise spontaneously as it seemed to do in moulds, or was there some “mechanism” to it?) One can imagine the primacy of such a question. Secondly though, it is thought that Christiaan Huygens’s sudden leap towards the simple microscope was nearly entirely triggered and faciliated by the young microscopist Hartsoeker, who not long too before had discovered this technique for himself. The two were in correspondence and in March 1678 Hartsoeker reveals to him his secret. As Edward Ruestow narrates in his wonderful history The Microscope and the Dutch Republic:

The announcement of the discovery of spermatozoa in the fall of 1677 arouses the particular interest of Christiaan Huygens and, through the young Hartsoeker, drew him belatedly to the bead microscope…but having heard of a young man in Rotterdam whose microscopes could reveal the recently discovered spermazoa, Christiaangot in touch with Hartsoeker.

The essential account of their first contact, which is Hartsoeker’s, is tainted by its entanglement with his later claim that he had in fact been the first to discover spermatozoa. The surviving correspondence begins with a reply from Hartsoeker in March 1678 in which he explained how he made the bead with which he observed the “animalcules” found in semen. He presented Christiaan with a number of these sphericals, as well as some wood and brass devices to hold them in place, and by the endofthe month had himself come to The Hague to show Christiaan the spermatozoa of a dog. Hartsoekercontinued to correspond with Christiaan about the employment and improvement of these instruments, all of which Christiaan meanwhile shared with his brother Constantijn. The following year Constantijn spoke of Hartsoeker as “the inventor of our microscopes,” and years later Christiaan recalled Harksoeker having taught them to make little spheres that served as lenses (24-25)

This is all very convincing. Christiaan, after many years of resistance to the idea of tiny spherical lenses, debating with Hudde and possibily Spinoza, spurred on by the need for more powerful magnfication due to the discovery of protozoa, bacteria and then the most importantly, the elusive key to life, spermatozoa, collaborates with a savantish, largely unknown young man from Rotterdam who even claims that had discovered the technique himself when he was a young boy, and suddenly is applying his own rather vast device-making knowledge to craft the best microscopes in Europe, presenting them to the Paris academy, confirming Van Leeuwenhoek’s discoveries only three and a half months after having learned how to bead lenses himself. Huygens is shopping his microscope across the continent, while Van Leeuwenhoek refuses to allow anyone to look into or even see his.

But the problems with this quick reversal narrative is subtle. For one the lens-bead techique is extremely simple. Hartsoeker himself said he discovered it while toying with a thread of glass and a candle. Swarmmerdam says that he could make 40 more or less servicable bead lenses in an hour. It also, as I have said, was rather ubiquitous. To recount: Huddehadbeen in possession of it at least since 1663, was willing to depart with it for at least Swammerdam and Monconys, andin fact had discussed its advantages with Huygens in April 1665. As M. Founeir describes Huygens’ objection to Hudde:

Hudde discussed the merits of these lense with Huygens [OCV, 308-9, 318, 330-1], who declined their use. He particularly deplored their very limited lack of depthof field. He foundit inconvenient that with such a small lens one could not see the upper and underside of an object, a hair for instance, at the same time (“Huygens’ Design…” 579).

Vossius, Huygens’s friend seems to be in possession of it then, and it is no doubt related to the “flea glasses” that Descartes speaks of in 1637, “whose use is quite common everywhere”.  Further, of course, when Hooke describes it in brief in his 1665 Micrographia, he exposes the method to the whole English reading world. This text Huygens remarkably had in his possession very soon after its publication, one of the few copies in Europe despite the Anglo-Dutch war of that year; and we have that copy, a section of which is annotated with Huygens’ hand.  Huygens had even been so kind to actually translate some of the English for Johannes Hudde.

Further in evidence that Christiaan Huygens was well-familliar with this lens, in November 1673 Hooke demonstrates to the Royal Society “microscope with only one globule of glass, fastened to an instrument with many joints” likely made in wide production by the Dutch instrument maker Musschenbroek. And even more conclusively, Christiaan’s own father Constantijn Sr. a few months later writes of a powerful “machine microscopique” used by both Swammerdam and Leiden professor of Botany Arnold Seyn (Ruestow, 24 n.96); and we know that Swammerdam later favored a single lens scope. Given their prevalence, simplicity andthe extent of Huygens’ likely intercourse with these lenses, it could not be that Christiaan Huygens and his brother were somehow deprived, waiting to be told how to bead glass by the 22 year old [Leiden student?] Hartsoeker? It may be imagined that perhaps Hudde kept his personal means of grinding tiny lenses secret from Huygens due to some competitive antagonism and Huygens’ obstinancyover the larger, compoundlens microscope design. Perhaps. But it could not be that all of educated Europe keep it a secret from one of the foremost scientific minds of the time. Something does not sit right. Was it simply Huygens’s disinterest in such a low-depth of field, simple lens, andhis proclivities for certain other types of lens formations (compound, like his telescopes) that kept him from wanting to know? Was Hartsoeker simply the expedient when Christiaan needed to catch up quickly? The way that Edward Ruestow tells it we get the sense that it merely took the interest of Huygens, the timely injection of technique, and then the application of the Huygens’ brothers marvelous technical sense. Perhaps.

But I suggest that one piece is missing from this puzzle. It may be not until the Huygenses acquired the lens-grinding equipment and lens examples from Spinoza’s estate that they possessed the technical means of polishing these small spherical bead lenses: a talent for minute polish which Spinoza had showed early on. Could it be that this was the link, the technical means which accelerated the rapid development of the Huygens microscope from concept to actuality?

The Huygens droplet design, as it ended up in late 1678

Ruestow cites the kinds of changes that the Huygens brothers made to the Hartsoeker lens technique, such as “removing the molten globule from the thread of glass withametal wire, or, with one end of the wire moistened, picking up small fragments of glass to fuse them into globules over the flame” (25). All these seem aimed trying to make the sphere smaller and smaller, increasing its magnification. In the endChristiaan would proclaim to his French audience that his microscope is not much different than those in Holland and England, other than the size of its smaller lens, supposedly something which he alone had achieved.

He also produced a casing that was built around this tiny lens, “mounting their own beads in small squares of thin, folded brass; with the bead trapped between the opposing holes pierced with a needle through the two sides of the folded brass, those sides were pinched together with hammered pieces of wire. The microscope would go through several revisions.

As Ruestow writes of its appearance in Paris:

“on July 16th he presented to the assembly the ‘new microscope’ he had brought back withhim from Holland – one that, according the the academy minutes, was ‘extraordinarily small like a grain of sand’ and magnified incredibly…before July was out, Christiaanusedthe instrument to show the members of the academy the microscopic life Leeuwenhoek had found in pepper water, soon after publishing the first public announcement of their discovery in the Journal des Sçavans, Christiaanalsoidentified it with the discovery of the spermatozoa.”

By August his microscope had caused the “great noise” all over Paris, so much so that John Locke at Blois had heard of it. Through the next year he had “cultivated the impression” that Van Leeuwenhoek’s observations were made with a microscope like his own. French instrument makers set to copying his invention. The response was not altogether gleeful. In London Hooke was somewhat put out that so much excitment surrounded what for him was a well-known device, one that he himself had fashioned, used and written of. And Hartsoeker, having finished his third year at the University at Leiden, all the while had been left in the shadows, not something that sat well with his rather conceitful temperment. Traveling to Paris Hartsoeker sought in some way to unmask his role in the creation of this remarkable device, exposing Huygens to be something of a plagerist. As Ruestow reports, knowing wisely Christiaan steered him from that course,

but [Christiaan] quickly took his younger compatriot under tow and wrote a brief report for him, published in the influential Journal des Sçavans, that asserted Hartsoeker’s active role in making new bead microscopes (27).

We have here evidence of Christiaan’s tendency to obscure the origins of his microscope. Yet was there more to the development than simply Hartsoeker’s revelation of the thread melting techique? Was it that in the purchase of Spinoza’s lens-polishing equipment they acquired something of the techiques long appreciated by the brothers? Does this technique prove essential to Christiaan’s implementation of a rather simple bead-glass lense? Was Hartsoekersimply solicited for the one remaining aspect of the technique that Spinoza’s equipment would not provide, that of simply melting the glass into a lens? We do know that the grinding of the already quite spherical bead was common among its users. For instance Van Leeuwenhoek ground and polished almost all of his tiny bead lenses, (and modern assayers do not quite know why). Further, Johannes Huddealsopolished his bead lenses, reportedly with salt. Was there something to Spinoza’s knowledge of small lens-crafting that facilitated Huygens’ suddenly powerful microscope design? Something even that Hartsoeker was privy to? And lastly, if Spinoza’s equipment and techniques are implimented in this sudden rise of the simple microscope, what does this say about Spinoza’s own microscope making practices.

All this fantastic story is just speculation of course

It could merely be a coincidence that, with Spinoza having died just as protozoa and bacteria were being discovered; and with his equipment coming into the hands of the brilliant Huygenses almost 9 months later, they they then just happen to be aided by a young microscopist that gives the means needed to suddenly develop a microscope that will sweep across Europe in merely a few months. Christiaan Huygens and his brother were brilliant enough for that. Perhaps Spinoza’s ginding dishes and recipes simply sat in the dust, having been acquired. But it should be noted that many years before this, the physcian Theodor Kerckring, a friend of Spinoza’s and a member of the inner, Cartesian circle, son-in-law to its central member Franciscus Van den Enden, writes of his use of Spinoza’s microscope:

“I have to my disposal a very excellent (praestantissimum) microscope, which is fabricated by that noble Benedictus Spinosa, mathematician andphilosopher…What I in this way discovered with the help of this admirable instrument…[are] endless many extremely small animalcula….”

This is found in his Spicilegium anatomicum published in 1670, seven years before Van Leeuwenhoek’s acclaimed description of the protozoa and bacteria in letter 18. It is not clear at all what “animalcula” Kerckring saw (some offer that they are post-mortum microbes, or mistaken ciliated action), but there is the possibility that these were the earliest microorganisms to be described, or at the very least, Spinoza had perfected an advanced form of the single lens, bead-microscope whose powers of magnfication approached many of those of Van Leeuwenhoek, and even that of its copist Christiaan Huygens. The timing remains. In November of 1677 the Huygenses lmay have acquired Spinoza’s lens grinding equipment, and in 8 months they have a microscope of remarkable powers.

Advertisements

Van Leeuwenhoek’s View of Technology and Spinoza

Part of this process of looking into the lensed conception of Spinoza’s metaphysics is understanding how at the cusp of a change in the technological interface – that is, with Descartes, an increased mathematization of nature and its corresponding instrumentization of devices – there also existed alternate conceptions of what viewing, observing and measuring entailed. The idea that a device could be of a fixed nature, a neutral embodiment of mathematics, and thus could be pointed in any direction, and at any number of objects, revealingly, is an imaginary simplification. Such a conception of device implies a certain invisibility of the mechanism in that the phenomena is simply shown for what it “is”, denuded. It is my sense that Spinoza, in his metaphysical grasp of the consubstantiality of the material and the ideationalas informed by his experiences as a maker of representational devices, and therefore instruments of both the micro- to macrological sort, conceived of instrumentation in a different kind of way. It was a way which may help inform us of our own potentiated relationship to technology. Rather than experiencing the object as simply being “revealed” it perhaps is better understood as staged, framed, part of an assemblage of observation and use. This is what alternate conceptions of technology may help us see.

In the personof van Leeuwenhoek, praised by history for his explorational conception of the micrological, a man who shared with Spinoza a merchant class origin, shunning for the greater part the fame of Scientific standing, we have a clue to something of the inveterate possibilities of instrumental use. I suggest below the example of the intimacy involved in van Leeuwenhoek’s experience of both his devices and his specimens. The “microscope” for him, was not understood, nor felt to be, a mechanism without context.

Pictured here is a composite drawing of van Leeuwenhoek’s “microscope” bringing together the significant features from the few surviving devices examined by Clifford Dobell. It shows boththe rod upon which a specimen needle is mounted, and the parallel plates between which a very fine lens would be inserted. The height of the specimen needle, and its proximity of it to the lens-plates, could be exactly and stably secured by the turn of screws. These devices are incredibly small, actually smaller than is pictured. What is significant about this device, other than its simplicity and size, is that the lens was so very small, its focal length could be less than 1/30th of an inch. The eye must be placed so as to be nearly touching the lens.

Van Leeuwenhoek made nearly five hundred of these palm-sized instruments, and famously was able to achieve magnification so as to vividly see bacteria and protozoa, the first of humankind to do so. Many of the plates were made of silver, and three of them are known to be made of gold, but none of them are in their material finely crafted in detail. They were tiny work-tools by van Leeuwenhoek’s conception. But there is something more about his concept that is important to dwell upon. After his fame had spread, some of the most important personages of Europe came to his merchant’s house in Delft to see these wonders. What is compelling is that he would let people view specimens on devices of only moderate magnification, and not sell a one. The most profound of his glasses, those upon which he made his most spectacular discoveries, he would not even allow a glimpse. People would ask him, bewildered, why would he make so many devices and never sell any. Various theories have arisen to explain this relation between van Leeuwenhoek and the number of his microscopes. Was he saving them up for sale by his daughter when he had passed? Was he secreting away the most precious facts of his observation capacities, making something of a mystery of it?

I think a clue to the number of devices is provided in the 26 samples he had sent to the Royal Society by his devoted daughter upon his death. None of the 26 are actually capable of the serious magnification that he must have attained in other devices, but each arrived, notably with their specimen already attached (the same is true for most of those auctioned off after his passing). The embryo of a Cochineal, or a thread of sheep’s wool, or the spinning organ of a spider’s abdomen was glued upon its requisite needle, perfectly positioned before its lens. One need only hold it up to light. I believe that far from conceiving of his microscopes as neutral devices which could be made machinically in relationship to laws of nature, and therefore could be turned ubiquitously upon any number of phenomena, each device was handmade for what was to be observed. He made so many devices because he had so many things to look at.

Why Did van Leeuwenhoek Refuse to Let Others Look?

Key to this device/object dyad is understanding that the viewing itself must have been a personal, intimate event. The staging of the specimen, the vice-like recursivity with which it was positioned to its glass, a minuscule glass sometimes ground just for that specimen, was an experiential revelation. As mentioned, the eye must be pressed so close as to practically touch the lens. In his most minute observations his microscopes and their specimens formed a circularity of object, means and eye that was physically closed.

There might be very good explanations why van Leeuwenhoek did not allow others – with the possible exception of his daughter, hired draughtsmen, and perhaps even anatomist Ruysch – to look into his strongest microscopic glasses, the obvious being his stated desire for secrecy; but beneath secrecy, most concerting was the likely intensive intimacy involved in these witnessings. And constitutive of this intimacy were two points. First was that Van Leeuwenhoek’s conception of minute observation was dioramic: frame and object met such that the frame was part of the view. It was an engagement. Secondly, because the device was small and could be held in the hand, and the eye was pressed so near, the consciousness of the viewer was a participation with the frame (metal plate and lens) as much as with the object viewed, so much so that there was no anonymity of vision. In a sense, perhaps van Leeuwenhoek came to feel that viewer could no more easily be exchanged with a particular device, than could its specimen. Individual glasses and individual objects matched, as did the eye, and as the magnification became more intense, so did the investment. This, I suggest, is what van Leeuwenhoek was protecting. One could say, just as one could not share dental braces, nor would not share contact lenses, van Leeuwenhoek refused to share the smallest of scopes. They fit his eye and his vision, prosthetically, and in terms of experience, privately. The math was thus affect-rich and context dependent.

(Could it be that there is closely related reason why van Leeuwenhook may have denied the privledge of looking into his strongest lenses? He was, admittedly, very sensitive to criticism. The game of assertion and denial was quiet unpleasant, and it was in part because of this sensitivity that he did not relish the thought of publishing his findings with the Royal Society at first opportunity. It could have been that this sensitivity extended itself to personal experiences as well. Van Leeuwenhoek was gifted. He had not only diligent powers of observation, but also incredibly acute eyesight, far better than even above average. It may have been likely that he had shown others, early on, his strongest glasses, and others simply could not see in them what he could see. His observations were, in a way, personalized to a more specific degree than even already mentioned, not just by context, but by capacity; he could not afford being told that what he saw simply was not there. They were is own assemblage.)

“…you then hold the microscope toward the sky…as though you had a telescope and were trying to look at the stars in the sky through it,”

he wrote of the process of illuminating a specimen. In such a view the conceptions of the linked Macrocosm and the Microcosm collapse into a single relational whole, (for one knew that optically a telescope could be turned into a microscope through a rearrangement of the lenses). But holding a specimen glass up to the light was more than this, it was a person’s investment in observation and device, and the one-to-one context between the specimen and its process of viewing that is exhibited by van Leeuwenhoek and his microscopes. This reflexivity of concept is shown everywhere in his staging choices, but perhaps none so evident as when he had carefully ground a grain of sand in order to see a smaller grain of sand, seeing sand with sand:

The two grains, one a lens, the other fixed in ratio, were viced into exact proportion. This speaks strongly to a closed and event-specific notion of technology, one which involves the viewer as well. The sand-sand-eye-sky’s light looping form an intimacy which opens up an alternate understanding of what observation is, one where what is being looked at cannot be cut off from its mechanism of viewing, nor from who is viewing. Instead it is a putting of objects, including one’s eye, into relation.

Van Leeuwenhoek, Technology and Spinoza

Van Leeuwenhoek lived but 4 miles from Spinoza in the summer of 1665, and it is not at all certain that he had even invented his viewing glasses at that point in time (the earliest record of his observations come during a trip to England in 1668; and some [Ford for instance] propose that he was originally inspired by Hooke’s Micrographia which would have barely reached Delft in 1665). Yet one imagines that it is quite likely that the history of van Leeuwenhoek’s experiments with glassblowing and lens-craft go back further than our first record of them in regard to his English, chalk-gazing holiday [Ruestow suggests that A.v.L. intimates a date as early as 1659]. It is conceivable that the two lens-grinders were both making lenses contemporaneously, a few miles apart. But the point really is not to establish a personal contact point between van Leeuwenhoek and Spinoza, though they do share a matrix of possible relations, it is rather to suggest a conceptual contact point. They are physically proximate and they are both of merchant families (not a small cultural fact). Each pursued knowledge in a hermited, semi-private way. Mostly, though, they likely embody a conception of technology and lens which was not part of the dominate instrumental conception of device; theirs was one where what is personally made (even if it is an instrument) is not divorced from the circumstances of its use, either by its object, or its witness. What van Leeuwenhoek’s technological conception potentially reveals for the Spinozist, is the thought that despite the prevailing mathematicization of Nature, brought forth by Descartes’ lead, the combinatory experience of observer, device and object remains a determining factor in the meaning of what was discovered. This is something that Spinoza brings out when he speaks of our experience of the Sun being only 200 hundred feet away despite our knowledge that it is much farther and larger (Ethics 2p35s): our essence and the sun’s essence interact to produce the affect of a meaningful, imaginary experience, a kind of phenomenal knowledge, a knowledge which, though inadequate and confused, makes up a greater portion of our world. Simply the crystalizing of the phenomenal image into clarity, making it large and sharp, was not enough for “knowledge” in Spinoza’s view. This was not the “clear and adequate” idea.

Spinoza’s notion of technology – in that he can be said to have one that we can conclude from his philosophy and assumed to be given through his experiences of lens and instrument making – calls our attention to the continual circumstance of our use, including our affective investments, and to the notion that object, device and eye are part of an assemblage of perception organized by our ideas. More than an ever more crispening of the image is the relation of that precision to our own exactness, and therefore for Spinoza, our own power. The conception is really Cybernetic.
